How to Replace a Trailer Hub, Bearings & Grease Seal

What This Guide Solves

  Follow the hub-removal and installation process step by step, then verify bearing numbers, seal size, bolt pattern and spindle fit before choosing the replacement hub.

February 11, 2026  ·  Paul Smith



R&P Carriages   /   Knowledge Hub   /   Running Gear

How to Replace a Trailer Hub, Bearings & Grease Seal

A practical, illustrated guide to identifying the right parts, removing the old hub, installing bearings and seals, and adjusting the spindle nut correctly.

R&P Knowledge Hub trailer hub replacement article illustration
R&P Knowledge Hub — trailer hub replacement. This is the existing article image from the store.

A wheel hub holds the wheel studs and rotates on bearings around the axle spindle. This guide covers conventional serviceable tapered-roller-bearing grease-lubricated hubs, including the common 3,500-lb #84 spindle family. It does not cover sealed cartridge bearings such as Dexter Nev-R-Lube, oil-bath assemblies, or specialized disc-brake rotor installations; those require their own manufacturer procedures.

Important: Never work under a trailer supported only by a jack. Chock the wheels remaining on the ground, support the frame with appropriately rated stands at manufacturer-approved lifting points, and follow the trailer/axle maker’s wheel-nut and bearing-adjustment procedures. Stop if the spindle, brakes, or hub show heat damage or serious scoring.

1. What you are looking at

Lippert exploded brake hub diagram identifying dust cap, spindle nut, bearings, hub, seal and brake assembly
Hub anatomy — visual reference for serviceable brake hub assemblies · Photo: Lippert.
Exploded trailer hub assembly identifying the grease cap, spindle hardware, bearings, races, and seal
ILLUSTRATED REFERENCE. Exploded trailer hub assembly identifying the grease cap, spindle hardware, bearings, races, and seal. Photograph or diagram: etrailer.

From outside to inside, a conventional hub has a dust cap, spindle-retaining hardware, outer bearing, hub with pressed-in bearing races, inner bearing, and rear grease seal. The spindle itself is part of the axle—not part of the replacement hub.

EXPLODED ORDER — NOT TO SCALE
Dust
cap
Nut +
retainer
Outer
bearing
HUB
+ races
Inner
bearing
Grease
seal
← Wheel / outside   |   Axle / inside →
Diagram 1. Simplified exploded order of a conventional grease hub. Actual retainers, washers, bearing and seal arrangements vary by axle; consult the manufacturer drawing.

2. Identify the correct replacement before disassembly

Do not order using only the trailer’s gross weight rating or the wheel bolt pattern. Read the axle tag, record the inner and outer bearing numbers, measure or identify the grease seal, and verify whether the existing hub is an idler hub or a hub-and-drum brake assembly. A replacement idler hub is not a substitute for a braked drum.

L44649Outer bearing
1.063 in nominal ID
L68149Inner bearing
1.378 in nominal ID
10-19 / 171255TBCommon standard seal: 1.719 in ID × 2.565 in OD
Diagram 2. Common standard 3,500-lb #84 hub references—not a universal fitment chart. Match stamped part numbers and the seal journal before ordering.

For example, R&P carries the complete Dexter 5-on-4.5 idler hub as SKU 824805-KIT (Dexter kit K08-248-90) and a one-wheel bearing service kit as SKU BK2-100-CAP. Both use L68149 inner and L44649 outer bearings in the verified listings. View Dexter complete hub · View bearing service kit.

Important: Some UFP boat-trailer hubs also use L68149/L44649 bearings but require a different seal journal and sometimes a different race. Do not substitute the standard 10-19 seal based on bearing numbers alone. See the UFP-specific SKU choices below.
Labeled view of spindle, brake shoe and brake magnet behind the removed hub
What a brake-equipped trailer axle looks like with the hub removed · Photo: Lippert.

3. Tools and materials

  • Wheel chocks, proper floor jack, and rated jack stands
  • Lug wrench and torque wrench (use the vehicle/trailer manufacturer’s wheel-nut torque chart)
  • Pliers, screwdrivers, dust-cap removal tool, and clean rags
  • Seal puller, seal driver or appropriately sized flat block, and suitable bearing/race drivers if replacing races
  • Approved high-temperature wheel-bearing grease compatible with the existing lubricant
  • New seals, any damaged retaining hardware, and correctly matched bearings/races or replacement complete hub
  • Calipers and original bearing or seal part numbers for confirmation

4. Step-by-step installation

1

Secure the trailer and remove the wheel

Removing wheel lug nuts after the trailer has been safely supported
Step 1 — Remove wheel lug nuts with correct socket · Photo: Lippert.

Park on a hard, level surface. Chock opposite wheels, loosen wheel lug nuts slightly while on the ground, lift only at approved points, support the trailer frame with rated stands, and remove the wheel. Keep all hardware clean and organized.

Trailer brake hub with the dust cap and lug studs identified
REFERENCE PHOTO 1. Trailer brake hub with the dust cap and lug studs identified. Photograph or diagram: Lippert.
2

Remove the dust cap and spindle retainer

Work gently around the dust cap flange to avoid bending it. Identify whether your spindle uses a cotter pin and castellated nut, a tang washer, or a manufactured nut retainer. Remove that retainer, then remove the spindle nut and washer. Do not discard reusable spindle hardware until you have verified its condition and the replacement requirements.

Technician removes the trailer hub dust cap, revealing the spindle nut
REFERENCE PHOTO 2. Technician removes the trailer hub dust cap, revealing the spindle nut. Photograph or diagram: Lippert.
COTTER PIN
∪
Through castellated nut
TANG WASHER
⊣
Tab folded into nut notch
NUT RETAINER
▤
Matched retainer system
Diagram 3. Typical retainer families, shown schematically; the correct adjustment depends on the actual axle system.
3

Slide off the old hub

Gloved technician sliding the existing hub assembly off its spindle
Step 4 — Slide the old hub away from the spindle · Photo: Lippert.

Hold the outer bearing to prevent it from falling. Pull the hub straight off the spindle, gently rocking it if necessary. If a bearing is seized to the spindle or the hub will not release without heavy force, stop and seek service; aggressive removal can ruin the bearing journal.

Removing the cotter pin from a spindle castle nut with pliers
REFERENCE PHOTO 3. Removing the cotter pin from a spindle castle nut with pliers. Photograph or diagram: Lippert.
4

Clean and inspect the spindle and hub

Spindle and brake assembly exposed, inspect for contamination, wear and damage
Step 5 — Inspect spindle and brake hardware before installing the new hub · Photo: Lippert.

Wipe the spindle with a lint-free cloth. Inspect the bearing journals and seal surface for discoloration, scoring, raised metal, grooves, rust, or evidence of overheating. Inspect the hub for cracks, damaged studs, and worn race bores. A damaged spindle is not repaired by installing a new bearing alone.

Exploded trailer hub assembly identifying the grease cap, spindle hardware, bearings, races, and seal
REFERENCE PHOTO 4. Exploded trailer hub assembly identifying the grease cap, spindle hardware, bearings, races, and seal. Photograph or diagram: etrailer.
5

Remove the old seal, bearings, and races if servicing the existing hub

Use a seal puller to remove the rear seal and lift out the inner bearing. Discard the old seal. If replacing bearings, replace their matching races (cups) as a matched set. Drive races evenly with suitable tools, avoiding damage to the hub bore; make sure each new race seats fully against its shoulder. If installing a complete new hub with races already installed, do not drive out the supplied races.

6

Pack the bearings with the correct grease

If your replacement bearings are not already appropriately packed, force compatible wheel-bearing grease through each roller assembly until grease emerges around the rollers on the opposite side. Work cleanly: grit and lint shorten bearing life. Follow the manufacturer instructions for pre-greased hub assemblies rather than repacking them unnecessarily.

Gloved technician packing tapered trailer wheel bearings with grease
REFERENCE PHOTO 6. Gloved technician packing tapered trailer wheel bearings with grease. Photograph or diagram: Lippert.
7

Install the inner bearing and a new rear grease seal

Place the greased inner bearing into the rear race. Apply the seal treatment recommended by the axle maker, position the new seal squarely with its sealing lip toward the grease cavity (unless the seal manufacturer directs otherwise), and drive it evenly by its metal outer edge with the correct driver. Never strike the seal lip directly; never force it excessively deep.

HUB CAVITY
Inner bearing + grease
SEAL
lip →
SPINDLE
seal journal
Diagram 4. Simplified seal positioning. The seal lip ordinarily faces the lubricant; always follow markings and the specific seal manufacturer’s instructions.
8

Install the hub, outer bearing, washer, and nut

Carefully slide the assembled hub onto the spindle without cutting the rear seal on spindle threads or shoulders. Install the greased outer bearing in its race, followed by the correct washer and spindle nut. Do not hammer the hub into place or mix incompatible bearing cups and cones.

9

Adjust the bearings for your exact axle and retainer

For the standard cotter-pin procedure in Dexter instruction 059-831-00: rotate the hub while tightening the spindle nut to approximately 50 ft-lb to seat the bearings; loosen the nut completely without turning the hub; finger-tighten until snug; then back off to the first castellated alignment and install/bend the cotter pin. Dexter specifies that the nut should be able to move with only cotter-pin restraint. This is a seating procedure, not a final 50-ft-lb spindle-nut torque. Other Dexter retainer systems have different instructions; use the sheet for the actual axle.

Spindle nut seating operation on a trailer brake hub
REFERENCE PHOTO 9. Spindle nut seating operation on a trailer brake hub. Photograph or diagram: Lippert.
Important: A spindle nut left fully torqued after seating can overheat and destroy tapered bearings. Never apply the above procedure to Dexter Nev-R-Lube cartridge bearings: those use a different, specifically torqued spindle-nut system.
10

Reinstall cap and wheel; inspect before towing

Technician reinstalling wheel lug nuts before final torque
Step 10 — Reinstall the wheel and torque hardware to wheel manufacturer specifications · Photo: Lippert.

Install the correct dust cap without crushing it. Confirm the hub rotates smoothly without binding or objectionable play; check brake components and readjust drum brakes as specified. Reinstall the wheel, lower as directed, and torque wheel lug nuts in the specified sequence to the wheel/axle manufacturer’s stated value—not a guessed universal number. Inspect for grease leakage, noise, heat, and loose hardware after an initial short, careful test run.

Finished trailer hub with the dust cap reinstalled
REFERENCE PHOTO 10. Finished trailer hub with the dust cap reinstalled. Photograph or diagram: Lippert.

5. R&P parts that match these example applications

These are actual SKUs from Need a Trailer Part. They are examples, not an assertion that they fit your trailer. Verify the wheel bolt circle, spindle bearing numbers, seal journal, race dimensions and hub/brake style before purchasing.

R&P SKU Product Check fitment
824805-KIT Complete Dexter 3,500-lb idler hub 5 on 4.5; L68149 / L44649; Dexter K08-248-90; one wheel.
824805-KITX2 Pair of Dexter 3,500-lb idler hubs Two 5-on-4.5 hubs for two compatible wheel positions.
BK2-100-CAP Standard bearing/race/seal service kit One standard 3,500-lb wheel; L68149 / L44649, 10-19 seal and cap.
10-19-LOTOF2 Two-pack 10-19 double-lip seals For confirmed 1.719-in seal journal and 2.565-in hub bore.
BK2-256 UFP / EZ Loader bearing kit UFP-specific hub with 1.68-in seal journal; do not treat as standard 10-19.
BK2-500 UFP 3,200–3,700-lb bearing kit Includes alternative UFP cups and seals; identify correct components before assembly.
13684U-KIT Zinc-plated UFP 3,700-lb hub kit 5 on 4.5 and 1.68-in UFP seal; not equivalent to standard 3,500-lb hub.
Trailer hub photograph from existing R&P Knowledge Hub article
R&P Knowledge Hub photo from the existing article. Confirm hub specification from the axle and bearing numbers—not the image alone.

6. The UFP difference: same bearings, different seal

A standard Dexter-style #84 hub often combines L68149 / L44649 bearings with a 10-19, approximately 1.719-in inner-diameter seal. Many UFP boat-trailer applications use those same bearing numbers but a 1.68-in inner-diameter seal and, in some models, a different inner bearing race. That dimensional difference matters: a seal must fit the spindle journal, and a bearing race must fit the hub bore.

For a UFP square-tube hub built after 2003, R&P describes BK2-256 as using a 1.68-in ID seal and special L68110 race. BK2-500 contains multiple UFP possibilities and requires selecting the components matching the original hub. For complete UFP replacement, see 13684U-KIT.

Before the trailer goes back on the road
  • Correct bearings, races, seal and hub are matched to the actual spindle and axle specifications.
  • Spindle nut adjusted and its locking device installed per the axle maker’s procedure.
  • Dust cap securely fitted; no grease on brake linings or braking surfaces.
  • Wheel lug nuts torqued in the specified sequence and to the correct specification using a torque wrench.
  • Wheel rotates freely with appropriate bearing end play; no binding, abnormal noise or wobble.
  • Test at low speed, monitor hub temperature cautiously and recheck wheel torque at the manufacturer-recommended intervals.
