Prodigy P2 Brake Controller 90885 with 2009-2020 Ford F-150 & Flex Plug 3036-P (90885-36)

tekonsha

Regular price $193.99

Prodigy P2 Brake Controller With 2009-2020 Ford & Lincoln Vehicles Plug And Play Harness
Part #: 90885 +3036

You have purchased your new Primus or Prodigy Brake controller, and want to just PLUG AND PLAY??? This is the O.E.M. plug fits many 2009-2016 Ford & Lincoln Vehicles, look at the list below, and before you order, confirm you have the mating plug under your dash!

Features:

  • Applies power to the trailer brakes in proportion to vehicle's deceleration
  • No level adjustment necessary - it adjusts itself to varying terrain as you drive
  • Works proportionally in reverse - great for backing into tough spots
  • LED display lights up blue
    • Digital display depicts voltage delivery to trailer during braking
  • Continual diagnostics check for proper connection, shorted magnet condition and much more
  • "Boost" feature gives users the ability to apply more initial trailer braking power when towing heavier trailers
  • Power-saving mode reduces drain on battery when vehicle is not in use
  • Unique pocket mount allows for flexible mounting options
    • Offers a replacement pocket and wiring harness (sold separately) to move the controller easily from one vehicle to another
  • Quick and easy disconnect feature allows user to remove and store the control when not in use.
  • Rotary, manual brake lever
  • Works with electric over hydraulic trailer brake systems
  • Limited ONE YEAR warranty

Specs:

  • Dimensions: 3-1/8" (W) x 5-1/8" (L) x 1-3/16" (H)
  • Made for up to four-axle trailer brake systems (8 Brakes)
  • Mounting: 360 degree vertical range
  • Boost levels increase power up 0%, 13% and 25%
  • Power saving sleep mode draws 3.6 milliamp

How the Prodigy P2 is different from the original Prodigy
  • More mounting options - 360 degree vertical rotation
  • More protection - reverse battery protection for vehicle and trailer breakaway systems
  • Works with electric over hydraulic trailer brake systems
  • Blue digital, LED display


 3036 - (2009-2016) Ford, Land Rover & Lincoln Vehicles Brake Control Wiring Harness


Specs:
Required: For vehicles without brake control adapters.

20 amp. Circuit Breaker (9506P) for 2-4 Brake applications

30 amp. Circuit Breaker (38630) for 6-8 Brake applications


Brake Control Wiring Adapter for Pre-Wired:

2015 - 2017 Ford, Expedition, All Styles 20 minutes
2009 - 2020 Ford, F-150, All Styles 20 minutes
2017 - 2020 Ford, F-250 Super Duty, All Styles 20 minutes
2017 - 2020 Ford, F-350 Super Duty, All Styles 20 minutes
2017 - 2020 Ford, F-450 Super Duty, All Styles 20 minutes
2017 - 2020 Ford, F-550 Super Duty, All Styles 20 minutes
2012 - 2016 Ford, Flex, w/Factory Tow Package 20 minutes
2012 - 2015 Lincoln, MKT, w/Factory Tow Package 20 minutes
2015 - 2017 Lincoln, Navigator, All Styles 20 minutes

Kit includes Pilot Controller, 3ft. long "plug and Play" connector for hookup to trucks listed above, to Tekonsha Pilot, Prodigy P-3, P-2, and Primus Brake Control (for use with other brake controls, connector can be removed).  Note, Rarely, some trucks do not have the "Tow Package", please confirm yours does before ordering. If you are not sure email us!
