Fulton T11000301 1,100 lbs Single-Speed 2-Way Manual Trailer Winch - Z-Max 600 Zinc Finish
Reliable hand-winching power for boat trailers, PWC trailers, and other pulling jobs that need a corrosion-resistant manual winch with smooth cranking and proven Fulton durability.
Overview
The Fulton T11000301 is a single-speed manual trailer winch built for dependable pulling performance in marine and trailer applications. Its 2-way ratchet design, 4.1:1 gear ratio, solid steel construction, and Z-Max 600 corrosion-resistant finish make it a strong choice for boat owners who want smooth operation and longer service life in wet environments.
Product video included in the overview for a quick visual look at winch operation and fit.
R&P Service Insight
This is the kind of winch that makes sense when you want straightforward, proven manual loading power without stepping up to a larger, heavier model. It is especially attractive for customers fighting corrosion on boat trailer hardware.
- Marine-friendly finish: Z-Max 600 zinc coating helps the winch stand up better in damp and salt-air conditions.
- Smoother cranking: Full-length drum bearings and oil-impregnated bushings reduce drag during loading.
- Flexible setup: Designed for use with strap or rope, so you can match the winch to the trailer and bow setup you already have.
R&P Knowledge Hub
Compatibility: Universal-fit manual pulling winch for boat trailers, PWC trailers, and similar horizontal pulling applications. Works with strap or rope sold separately.
Vehicle / System Fit: Best suited for trailer winch stands and recovery-style pulling setups that need a manual 1,100 lb rated line pull.
Installation Notes: Verify your winch stand bolt pattern, mounting space, and fastener grade before installation. Confirm your chosen strap or rope matches the application and trailer load.
Performance Insight: The value in this model is its balance of corrosion resistance, smooth crank feel, and practical capacity for small to mid-size marine trailer duty.
R&P Repair Insight
The most common mistakes with manual winches are mismatched capacity, missing line hardware, and using a pulling winch in a lifting application. Confirm the job before ordering so the winch, mounting stand, and strap or rope all work together.
- Check capacity: Make sure the trailer and loading conditions do not exceed the winch’s 1,100 lb rated line pull.
- Check the line setup: This winch does not include the strap, so verify your preferred strap or rope separately.
- Check usage type: This is a pulling winch for trailer loading and similar horizontal work, not an overhead lifting device.
Features
Single-Speed 2-Way Operation
Manual single-speed design with a 2-way ratchet system for controlled loading and positioning.
Z-Max 600 Corrosion Resistance
High-performance zinc finish helps protect the winch body and gears in wet and marine environments.
Smooth Crank Performance
Oil-impregnated shaft bushings and full-length drum bearings support easier, more efficient cranking.
Universal Trailer Fit
Universal-fit construction works with many common trailer winch stand setups when mounted correctly.
Specifications
| Specification | Detail |
|---|---|
| Part Number | T11000301 |
| Product Type | Single-speed manual pulling winch |
| Application | Boat trailer, PWC trailer, and utility pulling applications |
| Material / Finish | Steel construction with Z-Max 600 zinc finish |
| Key Measurement | 1,100 lbs capacity | 4.1:1 gear ratio |
| Fitment | Universal bolt-on trailer winch fit |
| Handle Length | 7 inches |
| Line Compatibility | Up to 20 ft x 2 in strap or 30 ft x 5/16 in rope, sold separately |
Fitment / Application
| Category | Details |
|---|---|
| Vehicle / System | Boat trailers, PWC trailers, and similar trailer winch stand setups |
| Primary Fit | Manual trailer loading where a corrosion-resistant 1,100 lb pulling winch is appropriate |
| Secondary Fit | Utility and horizontal pulling applications using compatible mounting and line hardware |
| Notes | Strap or rope is sold separately. This winch is intended for pulling only and must not be used for overhead lifting. |
Included Components
| Quantity | Item |
|---|---|
| 1 | Main winch assembly |
| 1 | 7-inch winch handle |
| Included | Mounting hardware |
| Included | Pre-installed internal bushings and drum bearings |
| Not Included | Winch strap or rope |
