1-5x4.75 Dexter 5 Lug 3500# Drums with Dexter 10" Never Adjust Backing Plate Right Side (945475-B-FSA-DEX-R)

Dexter

Regular price $129.99

1 - 5x4.75 Dexter 3500# Drum w/10" Never Adjust Dexter Backing Plate

Part Number: 945475-B-FSA-DEX-R

USA MADE




Complete Trailer Brake Setup, with a drum, seal, Bearings, Brake shoes, new hardware, backing plate, for one side of 3500# axles from Dexter, AL-KO, AXIS, Quality, and others!



Measurements from Center Bolt Hole to Center Bolt Hole is 2 7/8" on Backing Plate

This Kit Includes:
1- Genuine Dexter Brake backing plate, 10" x 2.25, RIGHT SIDE
1- New Dexter 10" brake drum, 4.75" bolt pattern with races already pressed in
All
 hardware to attach backing plates to axle mount plate (special 7/16 nuts).
All brake hardware, springs, levers, magnets, shoes, etc.
New inner grease seals
All New Wheel Bearings (Shipping loose with kit):
1 - 1.7" 10-19 seal
1 - L44649 bearing 1-1/16"
1- L68149 bearing 1-3/8"
5 - Matching lug nuts, 1/2-20
1 - New EZ Lube Dust Cap



If you have a 2.75" OD Tube and a Flange with 5 holes, (to bolt the brake plate to) your axle is the 7000# Axle

If you have a 2.25" axle tube and has a 4 bolt flange it is the 3500# axle.

If you have the smaller 1-5/8" axle tube and has the 4 bolt flange, it has the smaller 2000/2200# axle



This auction is for a trailer with a 5 bolt, 4.750" bolt pattern!  I stock all sizes, so please check my other auctions or specify you want a different size!




Note: We offer two different types of brake kits. Basic Kits & Complete Kits
Complete Kits are for adding brakes for the first time
Basic Kits are for adding brakes to a second axle or replacing them.

Make sure you double check that you are ordering the right bolt pattern before you pay
