Slipper Leaf Spring – 2" Wide, 26-1/8" Long, 5 Leaf (1203T3)
Part Number: 1203T3
Slipper-style trailer leaf spring commonly used on heavy-duty trailer suspension systems. This spring measures approximately 26-1/8" from the slipper hook to the spring eye and is designed for use in tandem-axle or single-axle slipper spring applications.
Features
- Slipper-style leaf spring for trailer suspension systems
- Five (5) leaf construction
- Designed for 2" wide spring hangers and hardware
- Nylon bushing installed in spring eye
- Commonly used on 7,000 lb axle applications (per pair)
Specifications
| Specification | Detail |
|---|---|
| Spring Type | Slipper leaf spring |
| Leaf Count | 5 leaves |
| Spring Width | 2" |
| Overall Length | 26-1/8" (slipper hook to eye) |
| Arch Height | 3" |
| Center Thickness | 2-3/8" |
| Capacity | 7,000 lb per pair (typical application) |
Designed for trailers using 2" wide slipper springs and compatible hangers. Spring length is measured from the end of the slipper hook to the center of the spring eye. Verify spring dimensions, capacity, and hanger configuration before installation.
