Match the part number, measurements and connection points that apply to your trailer.
| Part Number | Match the number stamped on the original bearing or seal. |
|---|---|
| Dimensions | Measure the mating surfaces when a number is unavailable. |
| Hub / Axle | Use capacity as context, not as the only fitment check. |
R&P Carriages custom trailer axle build for applications requiring a 3,500 lb axle, 57.75" hub face, 44.75" spring centers, underslung spring configuration, and 5 on 5-1/2" hub bolt pattern.
| Specification | Detail |
|---|---|
| Product Type | Custom trailer axle |
| Brand | R&P Carriages custom axle listing |
| Axle Capacity | 3,500 lb |
| Hub Face | 57.75" |
| Spring Centers | 44.75" |
| Spring Configuration | Underslung / under-slung spring setup |
| Bolt Pattern | 5 on 5-1/2" / 5 x 5.50" |
| Hub Style | 5 x 5.50" hubs |
| Build Time | Custom axle — approximately 30-day ship time |
| Shipping Note | $60 fixed shipping cost noted for this custom axle order |
| Category | Details |
|---|---|
| Vehicle / System | Trailer axle replacement or custom trailer build |
| Primary Fit | Trailers requiring a 3,500 lb axle with 57.75" hub face and 44.75" spring centers |
| Wheel Pattern | For wheels matching 5 on 5-1/2" bolt pattern |
| Spring Setup | Underslung configuration where the spring and axle layout match the trailer setup |
| Notes | Verify hub face, spring center spacing, spring-over/spring-under configuration, wheel bolt pattern, brake requirements, and trailer load requirements before ordering. Custom axle orders should be confirmed before production. |
This R&P Carriages custom 3,500 lb trailer axle is built for applications requiring a 57.75" hub face, 44.75" spring center spacing, underslung spring configuration, and 5 on 5-1/2" hubs. It is intended for buyers who need a measurement-specific axle rather than a standard off-the-shelf replacement.
Custom axle fitment depends on accurate measurements. Hub face, spring center spacing, spring orientation, and hub bolt pattern all need to match the trailer before production.
Compatibility: Built for trailer applications where the supplied hub face, spring center spacing, capacity, spring configuration, and wheel bolt pattern match.
Vehicle / System Fit: 3,500 lb trailer axle applications requiring a 57.75" hub face and 44.75" spring centers.
Installation Notes: Verify spring seat location, under-slung configuration, wheel bolt pattern, and any brake or hub requirements before installation.
Ordering Insight: Custom axles are measurement-specific. Once production begins, fitment depends on the accuracy of the supplied axle dimensions.
Built for the listed 3,500 lb trailer axle application and supplied dimensions.
Configured for trailer applications requiring a 57.75" hub face measurement.
Spring center spacing supplied as 44.75" for the specified trailer setup.
Includes the listed 5 x 5.50" hub bolt pattern for compatible wheels.
| Quantity | Item |
|---|---|
| 1 | Custom 3,500 lb trailer axle configured to supplied dimensions |
| Not Included | 5 x 5.50" hubs |
| Not Included | Brake assemblies, U-bolts, spring and mounting hardware |
