10K General Duty Equalizer Bolt Kit – 1" Center Bolt & 3/4" Dry Spring Bolt
Part Number: 10GD-BOLT-KIT
Hardware kit intended for use in 10,000 lb general duty trailer suspension systems. Includes commonly used equalizer and dry spring mounting bolts with matching lock nuts.
R&P Knowledge Hub
This is a dry hardware kit (no grease fittings). Designed for general duty suspension applications using equalizers and standard leaf spring eye connections.
Confirm bolt diameter, thread pitch, and length before ordering. Not compatible with wet bolt systems.
Features
- Designed for general duty tandem axle suspension systems
- Dry application hardware (no grease fittings)
- Includes center bolt, spring eye bolt, and lock nuts
- Commonly used with equalizers and leaf spring assemblies
Specifications
| Part Number | Description |
| 007-264-00 |
Hex head spring eye bolt 3/4"-10 thread x 4.50" length Dry application Includes matching lock nut Commonly used with 72-80 springs |
| 007-169-00 |
Hex head spring eye bolt 1"-8 thread x 5.50" length Dry application Includes matching lock nut Used with general duty spring configurations |
| 006-113-00 |
Lock nut 3/4"-10 thread Compatible with 3/4" spring eye bolts |
| 6-112 |
Lock nut 1"-8 thread Compatible with 1" spring eye bolts |
Verify suspension rating, spring configuration, and bolt dimensions before installation.
