2,000# A-Frame Camper Trailer Tongue Jack FREE SHIPPING Lift top wind
Replacement top wind A-frame jack for common 3-bolt drop-in trailer and camper tongue jack applications with a 2.2" center hole. Built for buyers replacing a worn, bent, seized, or missing manual tongue jack.
Key Measurements & Specs
| Specification | Detail |
|---|---|
| Part Number / SKU | EA2000 |
| Product Type | Top wind A-frame trailer jack |
| Rated Capacity | 2,000 lb |
| Overall Length Retracted | 21" |
| Overall Length Extended | 36" |
| Tube Travel | 14" |
| Quantity Included | 1 jack |
Fitment / Application
| Category | Details |
|---|---|
| Trailer Type | Common A-frame trailer and camper tongue jack applications |
| Mount Style | Drop-in A-frame mount with 3-bolt pattern |
| Center Hole | Common 2.2" jack hole |
| Mount Plate | 1/4" thick, 5" x 5" x 5" triangular A-frame mount |
| Bolt Pattern | 3-1/4" from center hole to center hole |
| Important Note | Verify your center hole size, 3-bolt pattern, jack height, and needed foot base or caster before ordering. |
Top Features
| Feature | Buyer Benefit |
|---|---|
| 2,000 lb Rating | Good replacement choice for many light-duty trailer tongue jack applications. |
| Top Wind Handle | Manual crank design keeps operation simple and familiar. |
| 14" Travel | Provides lift range for hitching, unhitching, and leveling the trailer tongue. |
| Common A-Frame Pattern | Fits many standard 3-bolt A-frame jack mounts when measurements match. |
Overview
The EA2000 is a 2,000 lb top wind A-frame trailer jack for common drop-in trailer and camper tongue jack mounts. It is intended for A-frame couplers using the common 2.2" center hole and 3-bolt mounting pattern. This is a practical replacement jack for trailers where the original jack is worn, hard to crank, damaged, or missing.
R&P Service Insight
Before replacing a tongue jack, confirm both the jack rating and the physical mount. Most issues come from assuming all A-frame jacks are identical without checking the center hole, bolt pattern, and working height.
- Measure First: Confirm your trailer has the common 2.2" center hole and matching 3-bolt mount.
- Check Height: This jack measures 21" retracted and 36" extended overall.
- Foot Base: Foot base is not included, so reuse a compatible base or order one separately if needed.
R&P Knowledge Hub
Compatibility: Designed for common A-frame trailer and camper tongue jack applications where the jack hole, 3-bolt pattern, and height requirements match.
Trailer / System Fit: Common drop-in A-frame jack mount with 2.2" center hole and 3-bolt pattern.
Installation Notes: Verify bolt pattern, jack clearance, handle clearance, coupler layout, and whether your trailer needs a foot base or wheel caster before installation.
Performance Insight: The 14" travel range helps raise and lower the trailer tongue for normal hitching, unhitching, and parked trailer support.
Brand & Fitment Note
Selling Brand: These jacks are sourced from Cequent Group, known for trailer equipment brands such as Fulton and Bulldog. The name sticker on the jack may vary.
Application Reference: Brand names are used as sourcing and application references only. The physical jack and fitment measurements should be verified before ordering.
What This Means: This listing is for one EA2000 2,000 lb top wind A-frame trailer jack. The exact label or name sticker on the jack may vary, but the jack is sold by the listed specifications.
Before Ordering: Verify capacity, mounting hole size, bolt pattern, retracted length, extended length, travel, and needed accessories before installation.
R&P Repair Insight
A-frame jacks are often replaced when the crank becomes difficult, the inner tube is bent, the jack no longer supports the tongue properly, or the trailer needs a fresh manual jack for reliable use.
- Capacity Check: Match the jack rating to the trailer tongue load requirement, not the full trailer GVWR.
- Mount Check: Confirm the trailer uses the common 3-bolt A-frame mounting pattern before ordering.
- Accessory Check: Foot base is not included; confirm whether your existing foot or caster will fit your setup.
Features
2,000 lb Top Wind Jack
Manual top wind A-frame jack with a 2,000 lb rating for compatible trailer tongue applications.
Common Drop-In A-Frame Fit
Designed for common trailer and camper A-frame jack mounts with a 2.2" center hole and 3-bolt layout.
14" Tube Travel
Provides useful lift range for hitching, unhitching, and supporting the trailer tongue while parked.
Replacement-Friendly Measurements
21" overall retracted length and 36" overall extended length help buyers compare against their existing jack.
Included Components
| Quantity | Item |
|---|---|
| 1 | 2,000 lb top wind A-frame trailer jack, part number EA2000 |
| Not Included | Foot base |
| Not Included | Wheel caster, mounting hardware, and additional accessories unless otherwise shown or selected separately |
