Novalite USA 88-BPUT-16 Premium 7-Way Brake & Lighting Harness Kit
Complete sheathed 7-way trailer wiring system designed for brake, lighting, auxiliary power, and rear harness distribution on compatible tandem-axle trailer applications.
Part Number: 88-BPUT-16 7-Way Round Blade System Tandem-Axle Brake Integration
Overview
The Novalite USA 88-BPUT-16 is a premium 7-way trailer brake and lighting harness kit built for clean trailer wiring installation from the tongue area through the rear lighting branches. This kit is organized around three harness modules: 01-8803-A, 02-8803-A, and 03-8803-A. It is intended to support electric brake wiring, lighting circuits, auxiliary power, and rear lamp connections on compatible tandem-axle trailer layouts where the harness length, connector style, and circuit configuration match the trailer.
R&P Service Insight
A full 7-way harness kit is a cleaner solution than piecing together loose wire, especially when the trailer needs electric brake wiring and rear lighting feeds routed through a protected mainline.
-
Cleaner Routing: Jacketed harness construction helps keep the trailer wiring organized from the front plug to the rear branches.
-
Brake Circuit Support: Designed for tandem-axle electric brake layouts with brake distribution through the mid-section harness.
-
Service-Friendly Layout: Modular harness sections can make installation, troubleshooting, and future replacement easier than loose-wire repairs.
R&P Knowledge Hub
Compatibility: Intended for compatible trailer applications using a 7-way round blade plug, electric brake wiring, and rear lighting circuits.
Vehicle / System Fit: Trailer-side 7-way brake and lighting harness system for compatible tandem-axle trailer builds, repairs, or rewiring projects.
Installation Notes: Verify harness length, wire routing, plug style, brake quantity, lamp connector style, and circuit color code before installation.
Performance Insight: A pre-organized harness system can reduce wiring mistakes, improve serviceability, and create a cleaner installation than building each circuit from loose wire.
Brand & Fitment Note
Selling Brand: Novalite USA
Application Reference: Any OEM-style language in this listing describes installation style or application type only. It does not identify this item as a genuine OEM-branded component unless specifically stated and verified.
What This Means: This listing is for a Novalite USA 7-way trailer brake and lighting harness kit for compatible trailer applications.
Before Ordering: Verify connector style, harness length, wire gauge requirements, brake axle layout, lighting connector style, circuit color code, and included components before installation.
R&P Repair Insight
Trailer wiring problems are often caused by poor grounds, exposed splices, incorrect color-code assumptions, or mismatched connectors. Before replacing a harness, compare the trailer’s existing circuit layout to the new harness and confirm every output before final mounting.
-
Ground Check: Confirm the trailer ground path is clean, secure, and compatible with the harness ground circuit.
-
Brake Check: Verify the number of brake assemblies and confirm the blue brake circuit is routed correctly before powering the system.
-
Lighting Check: Match left turn, right turn, tail/marker, ID, auxiliary, and reverse circuits to the trailer lamps before final connection.
Features
Complete 7-Way Trailer Harness System
Designed to support trailer brake, lighting, auxiliary power, and rear distribution circuits through a 7-way round blade trailer-side connection.
Three-Module Harness Layout
Includes the primary input harness, mid-section brake distribution harness, and rear lighting harness identified as 01-8803-A, 02-8803-A, and 03-8803-A.
Tandem-Axle Brake Integration
Configured for trailer layouts using electric brakes on tandem-axle applications where the harness routing and brake quantity match the trailer.
Rear Lighting Branch Design
Rear harness layout supports left/right stop, turn, tail, marker, and center ID lighting connections when matched to compatible trailer lamps.
Specifications
| Specification | Detail |
| Part Number | 88-BPUT-16 |
| Brand | Novalite USA |
| Product Type | 7-way trailer brake and lighting harness kit |
| Application | Trailer-side brake, lighting, auxiliary, and rear harness wiring |
| Connector Type | 7-way round blade / RV-style trailer plug |
| Harness Construction | Jacketed / sheathed multi-section harness design |
| Approximate Length | Approx. 25 ft as supplied in source copy; verify before installation |
| Axle Support | Tandem-axle trailer applications where brake and harness routing match |
| Wire Gauge | Source copy lists 10 AWG for brake/auxiliary circuits and 12–14 AWG for lighting circuits; verify against product labeling before installation |
| Listed Circuit Colors | White ground, blue electric brakes, brown tail/marker/ID, green right turn/brake, yellow left turn/brake, black auxiliary/12V feed, purple reverse/backup where equipped |
Fitment / Application
| Category | Details |
| Vehicle / System | Trailer 7-way brake and lighting wiring system |
| Primary Fit | Compatible tandem-axle trailers using a 7-way round blade connection and electric brake wiring |
| Secondary Fit | Trailer builds or repairs requiring rear stop/turn/tail, marker, center ID, brake, auxiliary, and reverse circuit support where equipped |
| Notes | Confirm trailer length, axle/brake count, connector style, lamp connector type, wire routing, and color-code compatibility before ordering or installing. |
Included Components
| Quantity | Item |
| 1 | Primary 7-way input harness, module 01-8803-A |
| 1 | Mid-section brake distribution harness, module 02-8803-A |
| 1 | Rear lighting and brake integration harness, module 03-8803-A |
| Included | Rear branch connections for compatible left/right stop, turn, tail, marker, and center ID lighting layouts |
| Not specified | Mounting clips, fasteners, lamps, brake assemblies, junction box, and installation hardware are not listed as included unless shown or stated separately. |
Verify all harness measurements, circuit colors, connector styles, brake wiring requirements, lighting connector types, trailer length, and included components before installation. Do not assume wire color alone confirms circuit function; test each circuit before final connection. OEM-style references describe installation style only unless the item is specifically identified as verified OEM.
