STUB-84-555-H-SQ — 3,500 lb Square Stub Spindle Repair Kit
Complete 3,500 lb Square Stub Spindle Repair Kit — designed for axle fabrication, trailer repairs, or custom builds. Includes all core components needed for a reliable, precision-fit spindle assembly using standard #84 parts.Included Parts
| Qty | Part Number | Description |
|---|---|---|
| 1 | 165649 | Inner Bearing (L68149) |
| 1 | 84555-1 | Race (L68111) |
| 1 | FA-SN100 | Oil / Grease Seal – Nitrile |
| 1 | HD-3500-KIT | #84 Series Hardware Set – Washer, Castle Nut, Cotter Pin, Dust Cap |
| 1 | SP-20484-SQ | Square Spindle for 3,500 lb Axle (#84) |
| 1 | SW1000 | Weld-On Stub Sleeve / Spindle Weld Collar |
| 5 | X1023R | Mounting Bolts |
Specifications
- • Axle Capacity: 3,500 lb (#84 Series)
- • Spindle Type: Square, weld-on stub
- • Bearing Journal: L68149 / 1.378" I.D.
- • Race Journal: L68111 / 2.328" O.D.
- • Seal Size: 2.75" x 3.779"
- • Hardware: HD-3500-KIT complete with dust cap and cotter pin
- • Material: Heavy-duty machined steel
Applications
Ideal for custom trailer fabrication, axle repair, or conversion projects requiring a #84 spindle with 3,500 lb capacity. Works with standard 5-lug hub assemblies, idler or brake hubs rated for 3.5K.
