Heavy-Duty 7-Way LED Rewire Kit – WIR-5000-KIT
Everything you need to rewire your trailer — in one complete kit.
The WIR-5000-KIT is a complete heavy-duty 7-way LED rewire kit for trailers and RVs. It includes all essential plugs, wiring, and lighting to replace an old harness or build a new one from scratch. Designed for rugged use and LED-ready performance, each component is selected for reliability, weather resistance, and compatibility with standard 7-way blade systems.
Common Applications
- Rewiring enclosed cargo, utility, or equipment trailers
- Upgrading older trailers to LED lighting and 7-way connectivity
- Custom or shop builds requiring heavy-duty wiring
- RV or camper retrofits needing long, corrosion-resistant runs
- Farm, landscape, and contractor trailers exposed to the elements
| Product ID | WIR-5000-KIT |
| Description | Heavy-Duty 7-Way LED Rewire Kit with 14-Gauge Multiconductor Wire |
| Category | Lighting / Wiring |
| Unit Price | Starting at $147.50 (25 ft model) |
| Variants Available | 20 ft, 25 ft, 30 ft, 35 ft, 40 ft wire lengths |
| Wire Gauge | 14-7 Multigauge Copper |
| Weight | Varies by length (6–10 lb average) |
| UPC / EAN | Does not apply |
| Unit of Measure | Each |
Kit Includes
- 12-706 – 7-Way Blade Trailer End Plug
- 12-707 – 7-Way Blade Truck End Plug
- 16687 – 7-Blade and 4-Pin Trailer Plug Tester
- M09300R – Maxxima ¾″ Round LED Red Marker Light
- L34-WC9B-1 – Tecniq License Plate Light with .180 Bullets
- J-25-AK – Jammy 2½″ Round Amber 4-LED Grommet Mount Light Kit
- WTC147M-5-XX – 14-7 Multigauge Trailer Wire (Select Length)
Features & Benefits
- Heavy-duty 14-gauge wiring rated for LED and brake circuits
- Color-coded conductors simplify installation and diagnostics
- Corrosion-resistant plugs and sealed LEDs for long service life
- Compatible with standard junction boxes and 7-way connectors
- Custom length options available to fit your trailer perfectly
Installation Notes
- Mount junction box near trailer tongue for easy access
- Secure harness along frame rails; avoid pinch points
- Test brake, turn, and tail circuits with the included plug tester
- Apply dielectric grease to all connections for corrosion protection
Need a custom length or help choosing the right setup?
Call or text 815-357-3292 for quick support and fitment questions.
