5,200 lb T52 Square Torsion Axle — 77" HF / 63" OB
SKU: 5200-77-63OB-LPIB-10D-655B-Complete
Complete 5,200 lb T52 square torsion axle configuration with 77" hub-face width, 63" outside bracket width, electric brakes, 6 on 5.5" hub-and-drum bolt pattern, 1/2" wheel studs, and U-Lube spindle specification.
Torsion axle capacity alone does not determine fit. Verify the hub-face and outside-bracket measurements, bracket profile and placement, 10° down starting arm angle, wheel pattern, brakes, and towing clearances against your existing axle.
Key Features
|
5,200 lb Rated axle capacity
|
Torsion Suspension T52 square configuration
|
|
Electric Brakes FWSA designation per supplied specification
|
U-Lube Lubrication spindle configuration
|
Specifications & Fitment
| Attribute | Specification |
|---|---|
| Capacity | 5,200 lb |
| Axle / tube | T52 square torsion |
| Hub face | 77 in. |
| Outside bracket width | 63 in. |
| Bracket configuration | Low-profile inner brackets (LPIB) |
| Starting arm angle | 10° down |
| Arm configuration | Long leg |
| Brakes | Electric; FWSA designation |
| Hub & drum bolt pattern | 6 on 5.5 in. |
| Wheel studs | 1/2 in. |
| Spindles | U-Lube |
| Configuration | Complete axle assembly |
Confirm exact bracket position, arm angle, spindle and brake details before ordering. The 77" hub-face and 63" outside-bracket dimensions are not interchangeable with other axle configurations.
Not a universal-fit axle. Confirm configuration against the trailer and existing axle. The manufacturer part number, exact FWSA brake designation, and any separate mounting hardware included in the package should be verified.
Contact R&P Carriages with your measurements and existing axle information.
VISIT NEED A TRAILER PARTAsk R&P About This Item
Call, text, or send your measurements. Your inquiry will include this item and its SKU.
Close Specifications Form
Include the measurements you have. This inquiry automatically identifies the product and SKU.
Need the axle installed?
R&P Carriages also handles trailer service and axle-related repair work.
How to Get It
Collect this item from our Seneca location. Please confirm availability before traveling.
Pick Up at R&P Carriages
This exact item is available from our Seneca, Illinois location and is not set up for standard shipping.
Seneca, IL 61360 R&P Carriages
Please confirm measurements and availability before making the trip. We want to make sure the item waiting here is the one you need.
